Bosch Centre of Excellence in Automation Technologies

In Pneumatics laboratory, we have following state-of the art equipments available which are all supplied by our technology partner Bosch Rexroth Limited, Germany.

• Mobile component carriers (DS3)
• Compressors

Basic Pneumatics Kit comprising of:

¬ Single action cylinder, d = 25 mm, h = 50 mm
¬ Double action cylinder, d = 25 mm, h = 100 mm
¬ 3/2-way valve G1/8, with spring return
¬ 5/2-way valve G1/8, with spring return
¬ 5/2-way valve G1/8, pulse
¬ 5/3-way valve G1/8, locked in center position
¬ Throttle check valve G1/8
¬ Quick-action ventilating valve G1/4
¬ Pressure controller G1/8, 0.5 to 10 bar
¬ 3/2-way valve M5, adjustable, 2 to 8 bar
¬ 3/2-way valve G1/8, time-delayed
¬ Shuttle valve G1/8, OR
¬ Dual-pressure valve M5, AND
¬ 3/2-way valve M5, button
¬ 3/2-way valve G1/8, button
¬ 5/2-way valve G1/8, button
¬ 3/2-way valve M5, dancing roller
¬ 3/2-way valve M5, idle return roller
¬ Pressure gauge 0 to 10 bar
¬ Filter regulator 3/2-way valve, 0.2 to 8 bar
¬ Filter regulator G1/8, 0.1 to 3 bar
¬ 3/2-way valve G1/8, 2-stage amplifier
¬ Reflex nozzle
¬ Load simulator d=25 mm, s=100 mm, m=3.4 kg
¬ Pressure display
¬ Pneumatic distributor, 6x



Electrical Pneumatics Expansion Kit comprising of:

¬ 3/2-way solenoid valve M5, spring return
¬ 5/2-way solenoid valve G1/8, spring return
¬ 5/2-way solenoid pulse valve G1/8
¬ 5/3-way solenoid valve G1/8, locked in center position
¬ Relay box 24V, 4 changers
¬ Relay box 24V, on-delay
¬ Relay box 24V, off-delay
¬ Switch and button box 24V
¬ Electrical cylinder switch with adapter
¬ Electrical position sensor with roller lever
¬ Mechanical pressure switch, 1 to 16 bar
¬ Display-box 24V, visual/acoustic
¬ Distribution box 24V


Electro-pneumatic Control Engineering Snap-in comprising of:

¬ Pressure Control Valve PN-ED02 SI
¬ Pressure Switch and Sensor 0 to 16 bar electrical SI
¬ Double action cylinder, d = 25 mm, h = 100 mm with sensor SM6
¬ Octagon cylinder DWZ d = 25 mm, H = 100 mm, SI
¬ Filter regulator 3/2-way valve, 0.2 to 8 bar
¬ Pneumatic distributor, 6x
¬ 3/2-way control valve G1/8 with rotary switch
¬ Pressure controller G1/8, 0.5 to 10 bar
¬ Software tool IndraWorks (single license)
¬ Compact Flash card with Firmware for user programming
¬ SPS module 2 analog inputs
¬ SPS module 2 analog outputs
¬ Input/output box 24V, 16x
¬ Distribution box 24V
¬ Switch and button box 24V
¬ Operating module BPS 5.2 + BPS 20.0 in 49 TE box
¬ Operating module BPS 6.1 + BPS 21.0 in 49 TE box
¬ Control pneumatics cable set
